Needle Valve with Integral Bonnet一体式针型阀
一体式针型阀Needle Valve with Integral Bonnet
High-pressure integral bonnet needle valves for precise flow regulation in instrumentation systems.High-pressure integral bonnet needle valves for precise flow regulation in instrumentation systems.
Available Configurations
可选型号配置
| Image | 图片 | Model Code | 型号代码 | Type | 类型 | Description | 说明 |
|---|---|---|---|---|---|---|---|
 | JZTA1-SK | Straight Needle Valve with Ferrule | 卡套直通针阀 | ||||
 | JZTA1-LWM | Male Straight Needle Valve | 外螺纹直通针阀 | ||||
 | JZTA1-LWF | Female Straight Needle Valve | 内螺纹直通针阀 | ||||
 | JZTA1-SKF | Female Straight Needle Valve with Ferrule | 卡套内螺纹直通针阀 | ||||
 | JZTA1-SKM | Male Straight Needle Valve with Ferrule | 卡套外螺纹直通针阀 | ||||
 | JZTA2-SK | Angle-type Needle Valve with Ferrule | 卡套角型针阀 | ||||
 | JZTA2-LWM | Male Angle-type Needle Valve | 外螺纹角型针阀 | ||||
 | JZTA2-LWF | Female Angle-type Needle Valve | 内螺纹角型针阀 | ||||
 | JZTA2-SKF | Female Angle-type Needle Valve with Ferrule | 卡套内螺纹角型针阀 | ||||
 | JZTA2-SKM | Male Angle-type Needle Valve with Ferrule | 卡套外螺纹角型针阀 | ||||
 | JZTB1-SK | Straight Needle Valve with Ferrule | 卡套直通针阀 | ||||
 | JZTB1-LWM | Male Straight Needle Valve | 外螺纹直通针阀 | ||||
 | JZTB1-LWF | Female Straight Needle Valve | 内螺纹直通针阀 | ||||
 | JZTB1-SKF | Female Straight Needle Valve with Ferrule | 卡套内螺纹直通针阀 | ||||
 | JZTB1-SKM | Male Straight Needle Valve with Ferrule | 卡套外螺纹直通针阀 | ||||
 | JZTB2-SK | Angle Needle Valve with Ferrule | 卡套角型针阀 | ||||
 | JZTB2-LWM | Male Angle-type Needle Valve | 外螺纹角型针阀 | ||||
 | JZTB2-LWF | Female Angle-type Needle Valve | 内螺纹角型针阀 | ||||
 | JZTB2-FM | F & M Angle-type Needle Valve | 内外螺纹角型针阀 | ||||
 | JZTB2-SKF | Female Angle-type Needle Valve with Ferrule | 卡套内螺纹角型针阀 | ||||
 | JZTC1-SK | Straight Needle Valve with Ferrule | 卡套直通针阀 | ||||
 | JZTC1-LWM | Male Straight Needle Valve | 外螺纹直通针阀 | ||||
 | JZTC1-LWF | Female Straight Needle Valve | 内螺纹直通针阀 | ||||
 | JZTC1-FM | F & M Straight Needle Valve | 内外螺纹直通针阀 | ||||
 | JZTC1-SKF | Female Straight Needle Valve with Ferrule | 卡套内螺纹直通针阀 | ||||
 | JZTC2-SK | Angle Needle Valve with Ferrule | 卡套角型针阀 | ||||
 | JZTC2-LWM | Male Angle-type Needle Valve | 外螺纹角型针阀 | ||||
 | JZTC2-LWF | Female Angle-type Needle Valve | 内螺纹角型针阀 | ||||
 | JZTC2-FM | F & M Angle-type Needle Valve | 内外螺纹角型针阀 | ||||
 | JZTC2-SKF | Female Angle-type Needle Valve with Ferrule | 卡套内螺纹角型针阀 |
Other configurations and special materials available upon request. 其他配置和特殊材料可按需定制。
Product Description
产品描述
The HTF-JZT series integral bonnet needle valves provide precision flow control for instrumentation, sampling, and bleed applications. The one-piece forged body with integral bonnet design eliminates a potential leak path compared to two-piece designs, offering superior reliability in high-pressure and high-temperature service. Available in straight, angle, and multi-port configurations with a wide range of end connections.
The HTF-JZT series integral bonnet needle valves provide precision flow control for instrumentation, sampling, and bleed applications. The one-piece forged body with integral bonnet design eliminates a potential leak path compared to two-piece designs, offering superior reliability in high-pressure and high-temperature service. Available in straight, angle, and multi-port configurations with a wide range of end connections.
Key Features
主要特点
- One-piece forged body with integral bonnet for leak-path reduction
- Precision-machined metal-to-metal needle and seat
- Blow-out proof stem design for safety at high pressure
- Available in straight, angle, and cross patterns
- PTFE or Grafoil packing options for varied temperature ranges
- Rising or non-rising stem bar stock options
- One-piece forged body with integral bonnet for leak-path reduction
- Precision-machined metal-to-metal needle and seat
- Blow-out proof stem design for safety at high pressure
- Available in straight, angle, and cross patterns
- PTFE or Grafoil packing options for varied temperature ranges
- Rising or non-rising stem bar stock options
Typical Applications
典型应用
- Instrument isolation and vent valves
- Sample system flow control
- Chemical injection and dosing lines
- Gauge and transmitter isolation
- High-pressure gas regulation
- Instrument isolation and vent valves
- Sample system flow control
- Chemical injection and dosing lines
- Gauge and transmitter isolation
- High-pressure gas regulation
Available Materials
可选材料
Technical Specifications
技术规格
| Model Series | 型号系列 | HTF-JZT |
| Size Range | 尺寸范围 | 1/8" – 1" NPT / 3mm – 25mm tube |
| Pressure Rating | 压力等级 | Up to 10,000 psi (690 bar) |
| Temperature Range | 温度范围 | -65°F to 850°F (-54°C to 454°C) with PTFE; to 1200°F (649°C) with Grafoil |
| Materials | 材料 | 316 Stainless Steel, 304 Stainless Steel, Alloy 400/Monel, Alloy C-276, Alloy 625 |
| Category | 类别 | ValvesValves |
